Hybrid CT20

Cable Tester

The Hybrid CT20 is a valuable tool for all applications where cables are being used for the first time, be it a permanent or temporary installation. Most system failures occur due to faulty cables so it is good practice to test all cables before using them. Hybrid offers 3 cable testing units with different testing ports to suit your needs.

The CT20 is a metal constructed tester powered by a 9V battery with LEDs indicating continuity and phase.

It is suited to test the following cables:

Speakon NL4 – Speakon NL4 Speakon NL4 – 1/4″ Jack 1/4″ Jack – 1/4″ Jack (Mono and Stereo) 1/4″ Jack – 3.5mm Jack (Mono and Stereo) 3.5mm Jack – 3.5mm Jack (Mono and Stereo) RCA – RCA XLR Male – XLR Female (Balanced/Unbalanced) XLR Male 5P – XLR Female 5P 5 Pin DIN – 5 Pin DIN HDMI – HDMI RJ45 – RJ45 (Ethernet) USB A – USB A USB A – USB B USB B – USB B USB A – Micro USB USB B – Micro USB Micro USB – Micro USB Powercon In – Powercon Out
