GROUND GLIDE 2000 Low Fog Machine

The Ground Cloud 2000 is a high-capacity water-based low fog machine designed for dramatic stage effects. With dual 2000W heating elements, DMX512 control, and wide-area coverage, it creates dense, lingering fog that stays close to the ground-perfect for concerts, theaters, and immersive events.

Category

Details

Power

2000W (dual heating elements)

Fog Type

Water-based low-lying fog

Control

DMX512 (2 channels), manual buttons, remote

Display

4-digit LED (shows address, airflow, fog density, timers)

Tank Capacity

1l

Weight

Setup & Operation

1. Initial Setup

2. Control Modes

Mode

Function

DMX512

CH1: Fog density (0-255), CH2: Airflow/start (≥50 = on)

Manual

Use panel buttons to adjust P000-P100 (airflow) and 4000-200 (timer)

Remote

Wireless control for fog activation

3. Digital Tube Display

Display

Meaning

UP-

Heating in progress

Ready for operation

A001

DMX address set to 001

P050

Airflow at 50%

Safety & Maintenance

⚠ Avoid Dry Operation - Always ensure water is present to prevent damage.

⚠ Ventilation - Do not use in enclosed spaces (fog reduces visibility).

⚠ Post-Use Care - Drain tank via water valve and wipe clean after each use.

⚠ High-Temp Warning - Heating elements reach extreme temperatures during operation.

DMX Channel Table (2 Channels)

Channel

Value Range

Function

1

0-255

Fog density (0 = off, 255 = max)

2

0-49: Off, 50-255: On

Activates fog pump + adjusts airflow

Package Includes:

1 × Ground Cloud 2000 Fog Machine

Water Drain Tube

Power Cable

User Manual
